ALPOLIC™ ACP
SKU: 1
Now available from Stratco throughout New Zealand, ALPOLIC™ is a global market leading Aluminium Composite Panel (ACP) brand, manufactured by Mitsubishi Chemical in Japan, United States and Germany. With over 50 years of experience in researching, developing and manufacturing ACP for architectural buildings, you can trust ALPOLIC™ ACP as an innovative, high-quality product backed by Stratco's customer service. Not only is ALPOLIC™ ACP aesthetically pleasing and highly versatile, it is high quality, sustainable and safe option. Designers, architects and builders all over the world rely on ALPOLIC™ ACP for the implementation of unique architectural projects - for both existing and new buildings.ALPOLIC™ ACP Features
ALPOLIC™ provides a range of great features that stem from the ALPOLIC™ coating and laminating technology, including:
- Flatness: Perfectly flat panel with high rigidity
- Perfect Finish: Consistent color and smooth coating
- Weather Resistant: Excellent corrosion and weather-resistance properties
- Lightweight Product: Significantly lighter than solid metals of equivalent rigidity
- Fire Performance: Fire retardant core and fire safe properties
- Workability: Easy to fabricate for versatile applications using common machinery and tools
- Sustainability: Recylcable material manufactured with care for the environment
Composition of ALPOLIC™ ACP
ALPOLIC™ ACP and its affiliated products commonly have the following composition.
ALPOLIC™ Product Range
View the full ALPOLIC™ ACP Product Range below.
ALPOLIC™ NC/A1 is a fire safe aluminium composite material. It has a non-combustible mineral core that does not contain any polyethylene. ALPOLIC™ NC/A1 can be applied as interior or exterior wall cladding or roofing. It is suitable for new buildings and refurbishments. It can be applied anywhere a non-combustible material is required.
ALPOLIC™ NC/A1 Composition
Standard Dimensions
- Thickness (tolerance +/-0.2mm): 4mm
- Width (tolerance +/-2 mm): 1270,1575 mm
- Bow tolerance: +/- 0.5% of the length or width
- Skin thickness: 0.5 mm
- Length (tolerance +/-1 m/m): 1800-7200 mm
- Diagonal difference: Max 5.0 mm
Characteristics (for standard dimensions)
ALPOLIC™ NC/A1 ISO Certifications
ISO 9001 : 2015 Certified
The production of ALPOLIC™ is ISO 9001:2015 compliant throughout the design, development, manufacture and sales.
ISO 140001 : 2015 Certified
ALPOLIC™ products are manufactured in factories that have ISO 14001 : 2015 certification.
ALPOLIC™ /fr surface coatings are finished with a high performance Lumiflon-based fluoropolymer coating (FEVE) as standard. The reverse side is coated with a protective polyester-based wash or service coating to guard against potential corrosion issues. This coating system offers several advantages compared to traditional PVDF coatings, including enhanced durability, a wider range of gloss levels, and the ability to achieve effects such as sparking, metallic, and prismatic finishes.
ALPOLIC™/fr Composition
ALPOLIC™/fr is made with a fire-retardant core between 2 skins of 0.5mm thick aluminum. Total thickness is either 3, 4 or 6mm. The topside is coated with fluorocarbon paint and the underside has a wash coating.
ALPOLIC™/fr Panel Dimensions
Thickness: 3, 4 and 6mm
Standard width: 965, 1270 and 1575mm
Length: Less than 7200mm
ALPOLIC™ A2 Color Options
There are 4 color types:
- Solid Colors
- Metallic Colors
- Sparkling Colors
- Patterns (Stone, Timber, Metal and Abstract).
All colors use fluorocarbon coating. Custom colors are also available for all finishes upon request with minimum quantiy requirements.
See standard color options below:
ALPOLIC™/fr-RF is a reflective finish aluminium composite material (ACM) with a reflective finish and a non-combustible mineral filled core. It is most commonly used for ceiling or interior wall applications.
ALPOLIC™/fr-RF Composition
ALPOLIC™/fr-RF is composed of a non-combustible mineral-filled core sandwiched between two skins of 0.5mm thick aluminium alloy.
ALPOLIC™/fr-RF Standard Panel Dimensions
Thickness: 3mm
Width: 1220mm
Length: 2440mm
ALPOLIC™/fr-RF Color Options
The ALPOLIC™/fr-RF surface is a reflective finish.
